Specifications
Scrollable
| MODEL | URG1204-CNCTS | URG1204-CNCT | URG1205-CNCTS | URG1205-CNCT |
|---|---|---|---|---|
| Control Type | Top Seat-Control | Base-Control | Top Seat-Control | Base-Control |
| Max. Lifting Capacity | 12,000 kg at 2.5 m | 12,000 kg at 2.5 m | 12,000 kg at 2.5 m | 12,000 kg at 2.5 m |
| Max. Hook Height | 17.7 m | 17.7 m | 21.02 m | 21.02 m |
| Max. Working Radius | 16.0 m | 16.0 m | 19.43 m | 19.43 m |
| Max. Boom Length | 16.36 m | 16.36 m | 19.79 m | 19.79 m |
| Min. Boom Length | 5.65 m | 5.65 m | 5.91 m | 5.91 m |
| Boom Sections | 4 | 4 | 5 | 5 |
| Boom Raising Angle | Min. -0.4° to Max. 76° | Min. -0.4° to Max. 76° | Min. -0.4° to Max. 76° | Min. -0.4° to Max. 76° |
| Slewing Angle | 360° Continuous | 360° Continuous | 360° Continuous | 360° Continuous |
